Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 303

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 303
799. DIAMOND MILLSTONE-DRESSING MACHINE. A Swiss machine lor dressing millstones. The frame, A, has arms, h, b, terminating in feet, c, which areprovided with set screw^s. A toolsupport, S, is pivoted to the centerof A, and is adjustable by means ofsector, B, and slides on the arm, C,of the frame.…
