Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 307

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 307
805. BAGGING AND WEIGHINGSCALES. A tripod on which is fixeda Roman balance with an extension yokeand funnel to which the bag is attachedby a band and chps. The beam of thebalance is made to counterbalance theyoke and funnel, and the tare of the bagis placed on the hook at the end of thescale beam.… … 806. AUTOMATIC BAGGINGAND WEIGHING MACHINE. The bag is attached to the hopperfunnel with its bottom resting onthe grated weighing platform. Thefeeding valve is then opened andconnected by an automatic latchto the weighing platform, whichdrops at a set weight of filHng, dis-engaging the latch, when…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
