Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 334

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 334
vided at its right-hand extremity with a pinion 2h feet in diameter. This engages witha small pinion that is mounted on the shaft that is rotated by the endlesschain from below. The draw is almost balanced by the weight of therollers. • 86i. TRANS-FER BRIDGE.A hanging trackon an…

Mechanical movements
