Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 389

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 389
t, while this is goingon, the upper end of the large magnet raises,by means of a guide wire, the tumbler D,which, just before the magnets come incontact, passes the perpendicular, and fallsover, carrying with it the lever connected with the two wheels, C, C, andcausing them to perform a quarter… … /^wM^yyyy//^/y//yyMyyyyy^y/y/yy//J^>yyy PERPETUAL MOTION. 2>^7 964. PERPETUAL MOTION. Magnetic wheel. A light wheelon friction rollers, set with slips of iron at an angle around its periphery. N, N are two magnets, which, attracting the rimof the wheel, will render one side lighter and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
