Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 44

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 44
turn-buckle is provided in the band for tightening the grip of the blocks.A very close regulation may be obtained by means of the various ad-justments, since the coefficient of friction fluctuates very slightly owingto excellent lubrication and absence of water from the friction surfaces.It is… … 56. TRANSMISSION DYNAMOMETER. The motor actsdirectly upon the axle of the wheel, A, in the direction shown by the arrow, and this wheel carries along theintermediate one, B, which transmitsmotion to the inner-toothed wheel. C.The latter is connected with the machineto be experimented upon by the…

Mechanical movements
