Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 65

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 65
An English type of approveddesign in whichthe steam issues inan annulus withinan annulus of oiland air at thethroat of a doublecone. Designedfor the most eco-nomical combus-tion of oil. 64 GENERATION OF POWER, STEAM. … 115. FUEL OIL BURNER. An air burner. Brown type.The air issues in an annular converging cone d, meeting the small jets of oil from the cen-tral apertures. Thecentral tube D alsoejects through thesmall holes a, a, a, a,fine jets of heatedoil; all forming thediverging cone e, e,e, e, of atomizedfuel.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
