Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 76

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 76
STEAM POWER APPLIANCES. 75 … 147. HIGH SPEED VERTICAL EN-GINE. Rhodes type. Valve of the gridironbalanced type, with valve gear of a novel de-sign giving a quick and full movement of thevalve through a rawhide disk, H, rolling on anirregular cam on the shaft and made adjustablefor time of cut off between the limit of ^g…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
