An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 85
84 STEAM POWER APPLIANCES. 172. engine. … TYPES OF SLIDE VALVES. Slide valve of the BrownellThe valve is of the box type, double-ported for both steamand exhaust, and practically perfectlybalanced. The steam pressure is re-moved from the back of the valve bymeans of a balance ring which bearsagainst the steam-chest cover. A coilspring…
