Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 85

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 85
v/z/z/z/y//////////// … 174. OSCILLATING STEAMAND EXHAUST VALVE, for hoisting engines. The valve isoperated by a direct rod from crank-pin arm to the valve arm. S, steampipe with passage around the cylin-der to the steam chest, P, P. Agood design to keep the cylinderclear of water. 175. Shows connection fromJ crank-pin…

Mechanical movements
