n inner flanged bonnet 0, having lantern-openings c for the admission of the fluid-pressure, and having radial and longitudinal pas-sages to obtain eflicicnt work of the valve. The valve section of the jacket is provided withribs supporting an inner jacket, which, with the bonnet, forms a chamber… … truss attached to the trunnion section of the jacket by bolts and keys. Tlie barrel is supportedon the truss by chairs which are adapted to transverse and vertical motion, so that the align-ment of the barrel can be easily adjusted. The gun-carriage A, mounted to turn upon a suit-able baso L, is…
