Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 94

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 94
verswings around k as a. fulcrum,and the valve is forced to theleft. This valve is an indirectvalve, that is, it takes steam atthe center and exhausts pastits outside edges—just the reverse of the ordinary D slide valve. Thelower end of the floating lever moving with the crosshead, it tends toswing… … 94 STEAM POWER APPLIANCES. movement of the reverse lever, buffer springs /, / are provided, whichgradually bring the moving parts to rest. In both gears shown, suitable stops in the valve chest prevent thevalve from being moved beyond the positions required for a full open-ing of the ports. 206.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
