xtends entirely through the diameter of the generator,forming, in fact, the connection between the two lowest coils ofthe White steam generator, and being connected at one end onthe point, Q, and at the other on the sleeve there shown. Withinthis tube, A, is another one, B, secured, as shown, to… … Fig. 417.—The White Thermostat Fuel Feed Regulator. A is a tube extend-ing clear through the body of the steam generator and forming theconnections of two of the coils, as at Q. B is a tube contained withinA, and around which steam circulates; C, a rod contained within B; D,a bell crank regulating…
