Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 329
®=a=^ZB … Fig. 233.—Automatic Governor and Hand Throttling Connections of theToledo Motor. The parts are: A, the suction pipe of the carburetter;B, the carburetter; B, the needle valve on the float chamber; C, thefloat chamber; D, throttle controller on rod, E; F, the governor lever;G, the sliding governor…
Automobiles
