Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 95

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 95
207. TRIPLE EXPAN-SION VALVE GEAR withsingle eccentric. A, eccentricstrap stay arm, which also oper-ates the high-pressure valve rod.B, bell-crank rock shaft thatoperates the medium - pressurevalve rod, linked to eccentricarm. C, rocker arm, shaft, andbell-crank connection by link tothe eccentric… … slotted link. The valve-rod block and rod is balanced by a weight onthe rock-shaft arm, and operated by a lever connected to the thirdarm. Valve lead is made by the crosshead arm Hnk and lever con-nected to the valve rod and hnk-block rod. Itahan railway. STEAM POWER APPLIANCES. 95

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
