Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 184
ore by the non-magneticbrass plug N. The puUing of the upper end of the lever G to theright carries the lower end to the left, separating it from the sta-tionary contact E, thereby breaking the circuit. Immediatelythe circuit is broken, the coil A surrenders its electro-magneticpower, the core F is… … Fig. 68.—Wiring diagram of a low tension system with magnetic sparkplugs. A portion of the wiring of the magneto armature is short circuited bythe platinum points of the interrupter, and when the circuit is broken, theresulting armature reaction has the effect of raising the armature…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
