Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 170

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 170
ELECTRIC POWER AND DEVICES. 167 … THREADS 397. CABLE COVER BRAID-ING MACHINE. Details of thebobbin motion, bobbin carrier gear,and slotted guide plate, a^ a are theguide fingers on the gears that pushthe bobbins along the grooves, whichby their crossing grooves carry thespools out and inside each other. 398. Shows the gears beneath…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
