Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 176

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 176
of air that is forced through the airpassage H, as the piston P moves in. Below this by-pass valve V, andin the piston P, is located a releasing valve, O, which can be adjustedat will to open by contact against the bottom of the dashpot, when thethrottle valve is near its seat, allowing the… … 416. SERIES ARC LIGHT-ING CIRCUIT. A multiseriesarc dynamo of the Brush system.The circuits may be combinedor single, controlled by a switch-board and three part armatureand commutator. 417. ROTATING ELECTRIC FUR-NACE. French design. The upper electrodeis swung in two directions and at the same…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
