Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 178

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 178
of air that is forced through the airpassage H, as the piston P moves in. Below this by-pass valve V, andin the piston P, is located a releasing valve, O, which can be adjustedat will to open by contact against the bottom of the dashpot, when thethrottle valve is near its seat, allowing the… … 416. SERIES ARC LIGHT-ING CIRCUIT. A multiseriesarc dynamo of the Brush system.The circuits may be combinedor single, controlled by a switch-board and three part armatureand commutator. 417. ROTATING ELECTRIC FUR-NACE. French design. The upper electrodeis swung in two directions and at the same…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
