Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 214

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 214
SECTION XII. ROAD AND VEHICLEDEVICES, ETC. 209 Section XII.ROAD AND VEHICLE DEVICES, ETC. … 534. ROADGRADINGWAGON. With shifting tonguedevice on theframe to allow ofclose scraping oneach side of theroad. An elevat-ing gear for the^ rake and scraper. 535. TRACTION WHEEL. In this wheel the projections of therim are yieldingly held, or they may be withdrawn entirely from the surface or held…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
