Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 220

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 220
557. STEAM SURREY.The boiler is placed under therear seat and the engine underthe front seat, from which thedriving by chain is extendedto a sprocket on the rear-axlecompensating gear. The boilerand engine are illustrated onother pages. ROAD AND VEHICLE DEVICES, ETC. 217 558. STEAM FREIGHT WAGON.… … Two-cylinder engine directly connected to a two-speed change-gearshaft and to a compensating shaft gear, which in turn is geared insideof the rear wheels.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
