Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 220

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 220
Two-cylinder engine directly connected to a two-speed change-gearshaft and to a compensating shaft gear, which in turn is geared insideof the rear wheels. … 559. Plan of steam freight wagon running gear, with change gearconnections. 2l8 ROAD AND VEHICLE DEVICES, ETC. 560. STEAM DRAY. Type of theLey land dray, much in use in England.Uses a kerosene burner under a verticaltube boiler, with double-reducing chain-gear system. Compensating gear on…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
