Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 233

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 233
597. TROLLEY REPLACER. The ]jj double spiral grooved cone carries a centralgroove A for the wire, and on each side ahelical groove, B, B, which quickly carries thewire to the central groove when displaced.Thus the conductor does not require any specialskill in replacing a displaced wheel, for if… … 598. CAR COUPLER. Washburn type.Has the side movement of the draw bar, andalso a movement of the head of the couplercontrolled by the side thrust of the helicalsprings for centering the coupler head.

Mechanical movements
