Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 255

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 255
erves formounting the spring drums andthe transmitting wheel C. At theouter end of said coil this spring,A, is attached to the hollow drum D mounted loosely on the shaft. Thisdrum has a central hub, E, extending along the shaft B within the seconddrum F, and the spring G in said drum is attached to… … MOTION AND CONTROLLING DEVICES, ETC. 253 663. SPRING MOTOR. A pair of shafts arranged parallel to eachother, and geared together so that one turns faster than the other, and a long India-rubber or otherelastic band or cord woundor coiled on the shaft whichmoves slowest, then attachedto the other…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
