Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 259

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 259
r L, and by depressing it locks the outside handle to the plug of the gascock. The opening ofthe cock by the handlesets a springand windsup a small clock move-ment, setting it in mo-tion. A small cam, C,is set in motion againstthe lever D, and re-leases the weight H,which has been liftedby the… … ® _ _ ® ^ —^—. L ^ 0 ® 678. SPIRAL FLUTING LATHE. The baluster is fed endwaysagainst a lateral tool, being rotated on its axis at such a rate as shall im-part the number of turns or part of aturn to the foot in length. Of thiskind is A, in which the piece a to becut is moved longitudinally…

Mechanical movements
