Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 101

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 101
the application ofthe invention to an upright en-gine. The eccentric is formedwith a hub having shoulders toengage a stop pin on the shaft,in combination with an operatingwheel placed on the hub of theeccentric, and having a limitedrotary motion thereon. Theeccentric has a Hmited inde-pendent…

Mechanical movements
