Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 259

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 259
in length. Of thiskind is A, in which the piece a to becut is moved longitudinally throughthe holder h, and at the same time isrotated so that the tool c in its revolu-tions may cut the spiral groove shownat a. 679. B is a fluting lathe in whicha pair of cutters revolve in a planeoblique with the… … MOTION AND CONTROLLING DEVICES, ETC. 257

Mechanical movements
