Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 341

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 341
. 1381. GEAR TRAIN, I? I with quick return, for a gear-i cutting machine. … 1382. QUICK RETURN MOVEMENT fora cutter head. A constant rotation of the camoperates the bell-crank sector, which is quicklydrawn back by the weight W and pinion C. 1383. REVERSING GEAR, from asingle belt and cone pulley. The gearwheel a has an outside and inside set ofteeth with the pinions ^, c…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
