Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 328

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 328
the hollow spindle, h, and beingheld in contact with the wire as the latter is slowly fed through the spindle,are wound uniformly over its surface, the spool frames revolving withthe spindles. The ends of the stems of leaves, fruits, or flowers being thrust into theends of the hollow spindle are at… … 837. FOUR-SPOOL HOISTING ENGINE.Mundy type. Friction drums with stop ratchetand pawl and friction-brake straps. Independ-ent clutch winches. All under control of fourhand levers and two foot levers. A most convenient type of com-bination hoist where a great vari-ety of work is in progress. Thetwo…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
