Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 350

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 350
ACE. English. Vertical and trans-verse sections of a double line of furnaces. The grates where the fire is made are shown at A. At B therefuse to be destroyed is shown in aninclined flue where it is being dried,and as it is consumed on the grate,descends on the slope of the flue,fresh matter being… … 348 MISCELLANEOUS DEVICES. 893. LIFE-SAVING NET. For bottom of elevator shafts. Astrong rope net, F, held on two sides by the rods, G, which are in turn supported on each end by thestrut arms C. The lower endsof these arms fit the bearingsin the pillow blocks, B, whiche are bolted to a stout plank,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
