Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 376

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 376
parts are mounted, aresupported by and extend between the two parallel rims, radial arms,and bosses of the wheel, b, c, d. e, e are curved arms working on axes orpivots, /, fixed in the rims; each arm carries weights, g, g, held in placeby adjusting screws g\ Each arm, e, terminates at its… … 929.wheel. PERPETUAL MOTION. The differential hydrostaticA, B, C, D are four vessels connected to the wheels, E, by roundpins which project from the vessels on eachside, and enter into corresponding holes inthe wheels E. The wheels, E, are in-tended to revolve by the space under thevessel, B, being…
