Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 321

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 321
ble ; but the subject is a valuablestudy. 316 TEXTILE AND MANUFACTURING DEVICES, ETC. 818. THREE-STRAND CORDAGE MACHINE. The armedcarrier wheels, K, H, T, are fast on the driving shaft. S. which is driven by a gear wheelmeshed with thethree pinions re-v o 1 v i n g thespools, G, for a5) back twist… … 820. THIRTY-TWO STRAND CORDAGE MACHINE. A fine studv of the mechanical motions required in this complicated

Mechanical movements
