Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 389

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 389
3^4 PP:KrETUAL MOTION. each other; but the tube, D, with its bulb swelled out, displaces a pintof water more than its opposite tube, and hence will attempt to rise withthe force of about one pound, and each tube, when it arrives at thesame position, must produce the same result; the wheel must have… … 957. PERPETUAL MOTION. Air-buoyed wheel. A is a cisternof water filled as high as line R; C are six bladders, communicating by the tubes, D, with the hollowaxle E, which axle is connectedwqth the bellows, F, by the pipe G.H is a crank, connected with thecrank, I, by the rod K. L is abevel w^heel, M…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
