Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 63

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 63
and lower furnace for obtaining aperfect circulation in the grate. 95. Longitudinal section of furnace. 6o GENERATION OF POWER, STEAM. 96. ANNULAR STEAM BLOW-ER. For boiler and other furnaces. Anannular cast-iron chamber perforated forsteam jets at an angle that projects thejets in a converging…
