Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 76

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 76
140. TYPES OF COMPOUNDENGINES. Cross compound withcranks at 120° on ends of shaft. Flywheel in center. In this type there isno dead center. 141. Low-pressure cylinder, showingrelative positions of piston. … 142. TYPES OF COMPOUNDENGINES. Twin compound, closeconnected tandem with high-pressurecylinders forward, cranks at 120° onends of shaft, fly wheel in center. 143. The relative positions of thepistons are shown in the two figuresat alternate strokes. 73 /4 STEAM POWER APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
