Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 93

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 93
the hook is engaged withthe die on the drop lever B, and as their rel-ative positions remain constant, they havinga common center of rotation, the end of B is raised, opening thevalve, which remains open until the bell crank has advanced so farthat the longer arm of the hook H is pressed outward by… … STEAM fOWER APPLIANCES. 9t 194. CORLISS VALVE GEAR. Allis-Chalmers type. Startingfrom the lowest position (not shown), the hook H, which is forced inward by the spring, engages with the droplever B, and as the bell-crank lever, A, A, movesin the direction indicated by the arrow, thelever B is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
