Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 94

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 94
196. REVERSING GEAR. Wolf type. E, is the eccentric; B, eccentric strap and arm ;/, a pin sliding in the hnk,S, which is moved to theposition S for reversing;a R, valve rod connected tothe eccentric arm at a. Theelliptic line, p, shows therange of the valve motionand swings to the vertical with the… … 92 STEAM POWER APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
