Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 95

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 95
on the driving shaft,and the driven ahead faces of the jaws, b^ on thedriven shaft. These pieces are lipped under thejaws at the bottom or inner end, to prevent themflying out while in motion. For the purpose oftaking up the backlash and compensating for anywear that might occur on the driving…

Mechanical movements
