Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 103

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 103
nd linked to the head and valve spindle,which are drawn down by the centrifugal actionof the balls. The regulation is made by the smallhelical spring and lever. The action is directthrough the spindle to the throttle valve. 228. MARINE GOVERNOR. Porter type.A cone pulley with screw-belt shipper for… … STEAM POWER APPLIANCES. 99
