Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 126
421. CENTRIFUGAL EXHAUST HEAD. —The exhaust steam head enters the drumtangentially, throwing the particles of wateragainst the outer surface to drip to the bottom. Section VI.MOTIVE POWER. GAS AND GASOLINE ENGINES, VALVE GEAR AND APPLI-ANCES, CONNECTING RODS AND HEADS. MOTIVE POWER. <jAs and… … 422. GASOLINE ENGINE, Olds model. Plan showinglocation of valve chest and valve gear, operated from an eccentric withan alternating sector gear for an impulse at every other revolution.
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
