Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 110

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 110
to the direction of run-ning it; and the maneuvering is very easily effected by means of asimple handle that actuates a toothed wheel that gears with the twococks. The motion of the piston ring is transmitted to the drivingshaft, D, through the intermedium of two symmetrical cams, E, unitedat their… … io6 STEAM POWER APPLIANCES. is placed a series of tempered steel balls that roll upon a correspond-ing path arranged in the interior of the piston ring. Two cheekstraversed bv the driving shaft close the cylinder at the sides, and aperfect tightness between these cheeks and the lateral faces of…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
