nut-tapping end, and Fig. 3470 is a similar view of the bolt-screwing end. The frame-work of the ma-chine A A, and the sole-plate B13, are cast in one piece. The driving-cone C is supported by the up-right frames near the centre of the machine, and carries a pinion D, of 15 teeth, which geers with…
