Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 114

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 114
STEAM POWER APPLIANCES. IO9 through the ports, r, at either end of the cylinders, the difference inthe diameters of the elliptical gears at the point of contact causes themain shaft elliptical gear, with the attached parts, to rotate. … 261. ROTARY ENGINE. Casadays pat-ent. A reversing rotary with adjustable cut off.A is the cut-off plug within an adjustable rotablecylinder and operated by an arm and connectingrod to the eccentric or the plug rotated bysprocket and chain. D, reversing plug. H, abut-ment block, cushioned by steam…

Mechanical movements
