Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 114

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 114
262. REVERSIBLE ROTARY EN-GINE. The piston when revolving in thedirection of the arrow takes steam by thethrow of a two-way cock; steam enteringthrough the diagonal slots in the abutmentpieces at /, /, and exhausting through theports e, c. Reversed by throwing over thesteam-cock opening to the… … 263. ROTARY ENGINE. Hodsontype. The valve U is operated by a camon the shaft S, to cut off for expansion.A, B, is a riding valve in contact with theelliptic cylinder, which has a packing slide,S, P, concentric with the axis and followingthe wall of the shell as a packing. Steam follows at half or…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
