Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 131

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 131
r the varying depth of a stream and toutilize the full value of the increased velocity at mid depth. Poweris transmitted to the shore, or may be used on the floats for pumpingwater for irrigation. 296. Cross section, showing wheel and frame. 297. WATER MOTOR. A curved bucket-rim wheel revolves… … HYDRAULIC POWER AND APPLIANCES. 127
