Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 138

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 138
ratedfor that purpose, and the pressure of the water upon the diaphragmkeeps it tight against the valve. The larger disk attached to the valvedisk serves as a deflector. When the solder is melted, the levers flyapart, and the valve and deflector drop about */a inch, leaving spacefor the water to… … 134 HYDRAULIC POWER AND APPLIANCES. 2nd TANK STIRRER 1st TANK :OR EMFTYING 323. DOMESTIC REFRIGERATOR. Water enters the coil atA, and is drawn into the tank at B, in which a quantity of nitrate of ammonia has been placedequal in weight with thewater. The cold pro-duced in the mixturecools the water…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
