Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 65
Fig. 43.—Sectional Elevation Of BronzePump-Valve. .-Spring Follower ..-Lock - NutSpring Conical-.Sew/- • … . BrassBrass Seat \ DiscBushing-- Brass ValveStuol Cast-Iron, Valve Deck Fig. 44.—Conical-Seated Pump-Valve With Brass Disc. or plate (P-Fig. 40) is used to stiffen the rubber disc andprevent warping. It also serves to protect the disc fromthe direct thrust of the spring (£-Fig. 40). The discs…
Steam power plants · Pumping machinery
