Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 144

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 144
333. PNEUMATIC BALL PUZZLE. A ball laid on the mouth of a flanged tube, as inthe cut, can not be blown off by an air jet, butwill continue to roll around on the flange, asshown by the dotted lines. 334. PNEUMATIC DISK PUZZLE. A light circular plate withpin guides can only be lifted a small distance…

Mechanical movements
