Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 173

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 173
\- mL … 401. SHUNT DYNAMOS con-nected in series. The shunt winding isconnected across both dynamos andthe other end of the winding to theopposite poles in the armature brushes. 402. SHORT AND LONGSHUNT. Compound dynamo wind-ing. Shows the two ways of makingthe terminal connections of the wind-ings.…

Mechanical movements
