Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 169

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 169
e brushes. 402. SHORT AND LONGSHUNT. Compound dynamo wind-ing. Shows the two ways of makingthe terminal connections of the wind-ings. Right-hand figure is shortshunt. 403. SEPARATELY EXCITEDDYNAMO. B, B are the brushesof the armature circuit to the linesM, M. The battery G supphes cur-rent to the… … ELECTRIC POWER AND DEVICES. 169

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
