Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 23

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 23
end. Tothe end of the arm, C, is pivoted a doubletree, D,on the outer end of which a singletree, H, is heldby a pin through one of a row of holes. The in-ner end of this doubletree is connected by loops,E, with the middle of the doubletree, B. Thedoubletree, D, is pivoted about one-third of its… … MECHANICAL POWER, LEVER. 19

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
